Timing Plot

Total Reductions to Date: 1

Date Processed: 06/09/2024 at 00:07:26 (PDT)

Exoplanet Watch Ephemeris

Parameter Value Uncertainty
Orbital Period (Days) 5.748134829704435 8.410763821721483e-07
Ephemeris (BJD_TDB) 2460056.7050080514 0.00033730664674023873
Time saved (hours) -

Assumed Priors

Parameter Value Uncertainty Units Reference
RA 176.2990518 decimal
DEC -42.0639575 decimal
Host Star Metallicity 0.15 0.09 Kokori et al. 2023
Host Star log(g) 4.53 0.02 Log10(cgs) Kokori et al. 2023
Host Star Radius [R_Sun] 0.9 0.02 Sol Kokori et al. 2023
Host Star Effective Temperature [K] 5900.0 100.0 K Kokori et al. 2023
a/Rs 15.2 0.4 Kokori et al. 2023
eccentricity 0.096 Maxted et al. 2016
inclination [degrees] 87.7 0.2 deg Kokori et al. 2023
omega [degrees] 0.0 deg Kokori et al. 2023
orbital period [days] 5.74813571 7.8e-07 day Kokori et al. 2023
Rp 13.24 0.64 R_Earth ExoFOP-TESS TOI
Rp/Rs 0.1109 0 ExoFOP-TESS TOI
ephemeris [JD] 2457745.95505 0.00012 BJD-TDB Kokori et al. 2023

Previously Published Mid-Transit Times

Value Uncertainty Units Reference
2457745.95505 0.00012 BJD-TDB Kokori et al. 2023
2458573.68658 0.00022 BJD-TDB Ivshina & Winn 2022
2459309.447174 0.000557 BJD ExoFOP-TESS TOI
2457027.4373 0.0002 HJD Maxted et al. 2016

Observations

Light curve chart for 0003316
Parameter Value Uncertainty
Am1 1.021 0.0026
Am2 -0.0109 0.0011
a/Rs 15.07 0.14
Rp/Rs 0.1214 0.0017
ephemeris [JD] 2460056.70203 0.00065
eccentricity 0.096
inclination [degrees] 87.7
omega [degrees] 0.0
orbital period [days] 5.74813571
u0 2.1496043537980145
u1 -3.7439428570802447
u2 4.0824764822596205
u3 -1.48813791814375
duration 0.1148 0.0015
