TOI-2046 b

View target in exoplanet catalog
Timing Plot
Global Light Curve
Lomb-Scargle Periodogram

Total Reductions to Date: 29

Date Processed: 10/03/2024 at 08:33:28 (PDT)

Exoplanet Watch Ephemeris

Parameter Value Uncertainty
Orbital Period (Days) 1.4971854432104728 1.3056472307666149e-06
Ephemeris (BJD_TDB) 2460476.730758165 0.0005229353358794904
Time saved (hours) 0.0026

Assumed Priors

Parameter Value Uncertainty Units Reference
RA 16.1849423 decimal
DEC 74.3313055 decimal
Host Star Metallicity -0.06 0.15 Kabáth et al. 2022
Host Star log(g) 4.3 0.15 Log10(cgs) Kabáth et al. 2022
Host Star Radius [R_Sun] 1.21 0.07 Sol Kabáth et al. 2022
Host Star Effective Temperature [K] 6250.0 140.0 K Kabáth et al. 2022
a/Rs 4.75 0.18 Kabáth et al. 2022
eccentricity 0.0 Kabáth et al. 2022
inclination [degrees] 83.6 0.9 deg Kabáth et al. 2022
omega [degrees] 0.0 deg Kabáth et al. 2022
orbital period [days] 1.4971842 3.1e-06 day Kabáth et al. 2022
Rp 16.14 1.23 R_Earth Kabáth et al. 2022
Rp/Rs 0.1275 0 ExoFOP-TESS TOI
ephemeris [JD] 2457792.2767 0.0024 BJD Kabáth et al. 2022

Previously Published Mid-Transit Times

Value Uncertainty Units Reference
2457792.2767 0.0024 BJD Kabáth et al. 2022
2459882.348171 0.000196 BJD ExoFOP-TESS TOI

Observations

Light curve chart for 0001875
Parameter Value Uncertainty
Am1 0.8009 0.0041
Am2 0.17 0.27
a/Rs 4.48 0.34
Rp/Rs 0.1653 0.0079
ephemeris [JD] 2459820.982 0.0067
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.9886092943987737
u1 -5.455092001708666
u2 5.296094711114577
u3 -1.829611924886724
duration 0.0904 0.0084
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
IJ Johnson I 780.0 nm 1020.0 nm
Organization Observer Code Secondary Observers
AAVSO LPAC (collaborate/publish)
Light curve chart for 0001877
Parameter Value Uncertainty
Am1 0.7954 0.0076
Am2 0.172 0.041
a/Rs 4.76 0.51
Rp/Rs 0.222 0.074
ephemeris [JD] 2459820.943 0.012
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.5027673984603576
u1 -4.541730010957516
u2 4.743239538647053
u3 -1.704276855470117
duration 0 0
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CBB Astrodon ExoPlanet-BB 500.0 nm 1000.0 nm
Organization Observer Code Secondary Observers
AAVSO LPAC (collaborate/publish)
Light curve chart for 0005055
Parameter Value Uncertainty
Am1 0.984 0.014
Am2 0.012 0.051
a/Rs 3.96 0.52
Rp/Rs 0.135 0.023
ephemeris [JD] 2459835.9387 0.0077
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8742324540899618
u1 -3.3661832740839968
u2 4.035195062192461
u3 -1.543244182069334
duration 0.126 0.017
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO SGGB (collaborate/publish) MOBS
Light curve chart for 0002030
Parameter Value Uncertainty
Am1 1.1294 0.004
Am2 -0.089 0.035
a/Rs 4.67 0.34
Rp/Rs 0.121 0.01
ephemeris [JD] 2459838.9256 0.0038
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.7763095871476753
u1 -5.010114875134687
u2 4.965670426580144
u3 -1.731865064598876
duration 0.103 0.01
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
I Cousins I 721.0 nm 875.0 nm
Organization Observer Code Secondary Observers
AAVSO LPAC (collaborate/publish)
Light curve chart for 0002050
Parameter Value Uncertainty
Am1 1.0166 0.0038
Am2 -0.0131 0.0082
a/Rs 4.772 0.081
Rp/Rs 0.119 0.003
ephemeris [JD] 2459877.85776 0.00098
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.4549321973729348
u1 -4.391721766388992
u2 4.5769752665827665
u3 -1.6401856293644639
duration 0.0997 0.0022
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0002936
Parameter Value Uncertainty
Am1 0.967 0.011
Am2 0.021 0.028
a/Rs 4.07 0.52
Rp/Rs 0.085 0.034
ephemeris [JD] 2459877.871 0.011
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8745189527215438
u1 -3.366600319957013
u2 4.036326407587579
u3 -1.5442449802061589
duration 0.108 0.014
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO BPIA (collaborate/publish) MOBS
Light curve chart for 0003498
Parameter Value Uncertainty
Am1 0.9925 0.0035
Am2 0.0053 0.0025
a/Rs 4.624 0.053
Rp/Rs 0.1183 0.0026
ephemeris [JD] 2459892.82701 0.00067
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.5030953689114686
u1 -4.54316473072559
u2 4.745490846362811
u3 -1.7054214138353654
duration 0.1037 0.0015
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CBB Astrodon ExoPlanet-BB 500.0 nm 1000.0 nm
Organization Observer Code Secondary Observers
AAVSO JJJA (collaborate/publish) SERC
Light curve chart for 0002161
Parameter Value Uncertainty
Am1 0.935 0.01
Am2 0.058 0.015
a/Rs 4.79 0.31
Rp/Rs 0.114 0.01
ephemeris [JD] 2459907.7996 0.0037
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.455203080896171
u1 -4.392292828650534
u2 4.577733524932005
u3 -1.6406437089640966
duration 0.098 0.0084
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0002230
Parameter Value Uncertainty
Am1 0.994 0.0047
Am2 0.0043 0.0055
a/Rs 4.78 0.1
Rp/Rs 0.1197 0.0034
ephemeris [JD] 2459931.7585 0.0012
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.4572031829728824
u1 -4.398264134998911
u2 4.584174384473165
u3 -1.6431133641376152
duration 0.0995 0.0028
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0002243
Parameter Value Uncertainty
Am1 1.0062 0.0049
Am2 -0.0038 0.0055
a/Rs 4.83 0.15
Rp/Rs 0.1486 0.0042
ephemeris [JD] 2459934.7479 0.0013
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.4564738427665858
u1 -4.395682778847407
u2 4.581332252797886
u3 -1.6421232484498947
duration 0.1015 0.004
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0005159
Parameter Value Uncertainty
Am1 1.021 0.013
Am2 -0.0112 0.0033
a/Rs 3.85 0.11
Rp/Rs 0.1272 0.0086
ephemeris [JD] 2459955.7036 0.0038
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0838587223489085
u1 -3.839602637382087
u2 4.414561263400505
u3 -1.6588172825852374
duration 0.1316 0.0048
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0005158
Parameter Value Uncertainty
Am1 0.98 0.01
Am2 0.0099 0.0023
a/Rs 4.75 0.26
Rp/Rs 0.1249 0.0068
ephemeris [JD] 2459967.6929 0.003
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.084696656757099
u1 -3.8434046335091687
u2 4.419838779756959
u3 -1.661130737144159
duration 0.1011 0.0074
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0002747
Parameter Value Uncertainty
Am1 0.88 0.013
Am2 0.066 0.049
a/Rs 5.33 0.51
Rp/Rs 0.046 0.072
ephemeris [JD] 2459979.677 0.011
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.084238213899043
u1 -3.840739304305738
u2 4.415863951736968
u3 -1.659362795528772
duration 0 0
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO OAS (collaborate/publish) MOBS
Light curve chart for 0003957
Parameter Value Uncertainty
Am1 1.028 0.011
Am2 -0.013 0.016
a/Rs 4.22 0.47
Rp/Rs 0.141 0.016
ephemeris [JD] 2460130.889 0.0063
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8745735053846728
u1 -3.367084227355132
u2 4.036262934784732
u3 -1.5437521526692688
duration 0.068 0.011
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO CCHD (collaborate/publish)
Light curve chart for 0004228
Parameter Value Uncertainty
Am1 1.006 0.015
Am2 -0.0006 0.0093
a/Rs 3.85 0.17
Rp/Rs 0.142 0.012
ephemeris [JD] 2460151.8227 0.0041
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.875274859101094
u1 -3.369576949962405
u2 4.039379094136069
u3 -1.5450769430833193
duration 0.134 0.007
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO CPHB (collaborate/publish) MOBS
Light curve chart for 0004541
Parameter Value Uncertainty
Am1 0.9707 0.0099
Am2 0.0186 0.0054
a/Rs 4.6 0.37
Rp/Rs 0.088 0.01
ephemeris [JD] 2460160.8247 0.0053
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0835293392252776
u1 -3.83852509691112
u2 4.413012503534287
u3 -1.658016680089434
duration 0.101 0.011
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0004342
Parameter Value Uncertainty
Am1 0.9846 0.0073
Am2 0.0096 0.0077
a/Rs 4.95 0.2
Rp/Rs 0.1198 0.006
ephemeris [JD] 2460181.7849 0.0019
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.4546851942692105
u1 -4.389198641071982
u2 4.573324468758963
u3 -1.638810953808346
duration 0.0949 0.005
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0004391
Parameter Value Uncertainty
Am1 1.0097 0.0043
Am2 -0.0066 0.0041
a/Rs 4.74 0.1
Rp/Rs 0.1356 0.0035
ephemeris [JD] 2460184.7791 0.0011
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.454478914440996
u1 -4.389079812101707
u2 4.573212705756374
u3 -1.6386117399494826
duration 0.1027 0.0029
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
RJ Johnson R 590.0 nm 810.0 nm
Organization Observer Code Secondary Observers
AAVSO MBEB (collaborate/publish)
Light curve chart for 0004349
Parameter Value Uncertainty
Am1 0.983 0.011
Am2 0.012 0.011
a/Rs 5.19 0.25
Rp/Rs 0.14 0.016
ephemeris [JD] 2460184.7765 0.0038
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.082809881020604
u1 -3.8359710860625498
u2 4.409971877034236
u3 -1.6568106062785892
duration 0.0911 0.0064
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO CPHB (collaborate/publish) MOBS
Light curve chart for 0004526
Parameter Value Uncertainty
Am1 1.022 0.011
Am2 -0.0132 0.0063
a/Rs 4.29 0.17
Rp/Rs 0.1389 0.0063
ephemeris [JD] 2460190.7728 0.0023
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0830968870312163
u1 -3.836533517676499
u2 4.409966392532269
u3 -1.6565296961733664
duration 0.1166 0.0059
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0004527
Parameter Value Uncertainty
Am1 0.946 0.013
Am2 0.0388 0.0094
a/Rs 3.85 0.12
Rp/Rs 0.156 0.0075
ephemeris [JD] 2460193.7545 0.0041
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0829473582339015
u1 -3.837761324487917
u2 4.413187937293048
u3 -1.6583739052774074
duration 0.1356 0.0053
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0004528
Parameter Value Uncertainty
Am1 1.0066 0.0094
Am2 -0.0043 0.0074
a/Rs 4.8 0.21
Rp/Rs 0.1442 0.0063
ephemeris [JD] 2460196.7595 0.0021
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0837344090568815
u1 -3.8388554793399656
u2 4.413488492216438
u3 -1.6583673561672514
duration 0.1018 0.0059
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0004685
Parameter Value Uncertainty
Am1 0.989 0.013
Am2 0.007 0.015
a/Rs 3.85 0.47
Rp/Rs 0.127 0.013
ephemeris [JD] 2460217.7143 0.0081
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8737082132104173
u1 -3.3635845888094327
u2 4.032268563616275
u3 -1.5423921279317758
duration 0.132 0.02
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO CPHB (collaborate/publish) MOBS
Light curve chart for 0004745
Parameter Value Uncertainty
Am1 1.0288 0.0096
Am2 -0.019 0.0075
a/Rs 5.08 0.24
Rp/Rs 0.1256 0.0075
ephemeris [JD] 2460232.6881 0.0026
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0841853092052736
u1 -3.841368710509343
u2 4.416847113979237
u3 -1.6596636468590171
duration 0.0923 0.0059
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV MObs CV 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO PMIF (collaborate/publish) UNIS
Light curve chart for 0004861
Parameter Value Uncertainty
Am1 0.902 0.017
Am2 0.067 0.031
a/Rs 5.04 0.54
Rp/Rs 0.0 0.028
ephemeris [JD] 2460244.674 0.012
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8748698087773097
u1 -3.3678622021714997
u2 4.037221488304313
u3 -1.5442290347508347
duration 0.073 0.012
Not included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO CPHB (collaborate/publish) MOBS
Light curve chart for 0004910
Parameter Value Uncertainty
Am1 1.189 0.02
Am2 -0.116 0.026
a/Rs 5.65 0.29
Rp/Rs 0.149 0.021
ephemeris [JD] 2460250.6619 0.0065
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.8747684891467649
u1 -3.3681634141277055
u2 4.037638593760865
u3 -1.5442436086144204
duration 0.0817 0.0064
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
V Johnson V 502.8 nm 586.8 nm
Organization Observer Code Secondary Observers
AAVSO CPHB (collaborate/publish) MOBS
Light curve chart for 0005945
Parameter Value Uncertainty
Am1 1.0097 0.0052
Am2 -0.0063 0.0032
a/Rs 5.06 0.11
Rp/Rs 0.1153 0.0036
ephemeris [JD] 2460321.0217 0.0012
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.1987832825357954
u1 -4.045394861090077
u2 4.53426759352405
u3 -1.6876559474039157
duration 0.0918 0.0028
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
NA Custom 400.0 nm 900.0 nm
Organization Observer Code Secondary Observers
AAVSO GTAB (collaborate/publish) UNIS
Light curve chart for 0005607
Parameter Value Uncertainty
Am1 0.9747 0.01
Am2 0.0171 0.0065
a/Rs 4.74 0.29
Rp/Rs 0.1164 0.004
ephemeris [JD] 2460367.4361 0.0033
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 1.881703194799594
u1 -3.4487076545459514
u2 4.168314120545279
u3 -1.6013095986862007
duration 0.1005 0.0081
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
NA Custom 400.0 nm 700.0 nm
Organization Observer Code Secondary Observers
AAVSO CJOB (collaborate/publish)
Light curve chart for 0006480
Parameter Value Uncertainty
Am1 0.9863 0.0064
Am2 0.0094 0.0051
a/Rs 4.73 0.13
Rp/Rs 0.1214 0.005
ephemeris [JD] 2460476.7329 0.0016
eccentricity 0.0
inclination [degrees] 83.6
omega [degrees] 0.0
orbital period [days] 1.4971842
u0 2.0831998458879637
u1 -3.839090806713605
u2 4.415023928434744
u3 -1.6591329018201195
duration 0.1011 0.0036
Included in ephemeris calculations
Light Curve ( PNG, PDF - high resolution )
Posteriors ( PNG, PDF - high resolution )
Observation Data ( JSON )
Filter Detail Min Max
CV Clear (unfiltered) reduced to V sequence 350.0 nm 850.0 nm
Organization Observer Code Secondary Observers
AAVSO AAMF (collaborate/publish)

Explore Alien Worlds

Exoplanet Travel Bureau

This set of travel posters envision a day when the creativity of scientists and engineers will allow us to do things we can only dream of now.
More

Strange New Worlds

Explore an interactive gallery of some of the most intriguing and exotic planets discovered so far.
More
A planetary tour through time. The ancients debated the existence of planets beyond our own; now we know of thousands.

Historic Timeline

A planetary tour through time. The ancients debated the existence of planets beyond our own; now we know of thousands.
More
